Technical Scope of Calibration

DIM-01.01 // REFERENCE STANDARDS

Gauge Blocks

Evaluation of longitudinal length, parallelism, and surface topography for both metric and imperial slip gauges. Calibration is performed via high-precision comparison against master sets.

DIM-01.02 // PRECISION MICROMETRY

Micrometers

Multi-point testing for external, internal, and depth micrometers. We verify displacement accuracy, anvil parallelism, and flatness using optical flats and master standards.

DIM-01.03 // LINEAR STANDARDS

Calipers (Vernier & Digital)

Standard verification of measuring jaws for internal and external dimensions. Includes parallelism inspection of jaw faces and depth rod accuracy checks across full range.

DIM-01.04 // VERTICAL METROLOGY

Height Gauges

Testing of 1D and 2D height gauges on granite datum planes. We calibrate for linear displacement and the squareness of the vertical measuring column.

DIM-02.01 // INDICATOR STANDARDS

Dial Test Indicators

High-resolution calibration of dial and digital indicators. Testing for linearity, repeatability, and hysteresis over the measuring range for lever and plunger types.

DIM-02.02 // LIMIT GAUGING

Plain Plug & Ring Gauges

Verification of "Go" and "No-Go" limits for precision bore and shaft inspection. Ensures dimensional stability and compliance for production quality control.

DIM-02.03 // THREAD METROLOGY

Screw Plug & Ring Gauges

Analysis of thread Major, Minor, and Effective diameters. We provide calibrated certification for a wide variety of metric and imperial thread profiles.

DIM-03.01 // ANGULAR GEOMETRY

Sine Bars & Sine Tables

Measurement of center-to-center roller distance and physical parallelism. Essential for creating absolute trigonometric angular references in inspection labs.

DIM-03.02 // ORTHOGONALITY

Engineer's Squares

Verification of perpendicularity (90°) for block, cylindrical, and blade squares using master cylinders and indicators to verify absolute squareness.

DIM-03.03 // FLATNESS & DATUMS

Surface Tables

On-site or in-lab mapping of overall flatness for granite and cast iron plates. We provide a full topographical profile for critical inspection baselines.
